OBN992-C81 | Bronze Gear Pump with Motor 1/4 Hp, 12V, 1200 Rpm | (N992)
SKU: obn992-c81
SKU: obn992-c81
Key Features:
- Material: Bronze housing, stainless steel shaft
- Port Size: 3/8" NPT
- Seal Type: Buna (NBR) lip seal (standard); FKM, PTFE, and mechanical seals optional
- Motor: 1/4 HP, 12V DC, 1200 RPM
- Max Pressure: 150 PSI (lubricants), 100 PSI (non-lubricants)
- Max Speed: 1750 RPM
- Temperature Range: 32°F to 140°F (standard); consult factory for extended range
- Bearings: Carbon graphite, self-lubricating
- Mounting: Close-coupled to DC motor
- Suction Lift: Up to 20 feet
- Drive Options: Direct motor coupling
Lead times temporarily extended to 12 weeks.
$2,487.00
Prices for items exclude shipping costs and taxes. Depending on your delivery address, taxes may vary at checkout.The OBN992-C81 is a bronze close-coupled rotary gear pump with an integrated 1/4 HP, 12V DC motor operating at 1200 RPM. Designed for compact and efficient fluid transfer, this positive displacement pump delivers consistent flow and pressure with excellent corrosion resistance.
Constructed with bronze housing, stainless steel shaft, and carbon graphite bearings, the OBN992-C81 ensures quiet operation and long service life. It is ideal for mobile and battery-powered systems requiring reliable performance in a compact footprint.
Recommended Applications:
Ideal for transferring oils, lubricants, and compatible chemicals in mobile, marine, and OEM systems requiring compact, corrosion-resistant, and pressure-stable performance. Not suitable for abrasive or solid-laden fluids.
Constructed with bronze housing, stainless steel shaft, and carbon graphite bearings, the OBN992-C81 ensures quiet operation and long service life. It is ideal for mobile and battery-powered systems requiring reliable performance in a compact footprint.
Recommended Applications:
Ideal for transferring oils, lubricants, and compatible chemicals in mobile, marine, and OEM systems requiring compact, corrosion-resistant, and pressure-stable performance. Not suitable for abrasive or solid-laden fluids.
