OBN992-C81 | Bronze Gear Pump with Motor 1/4 Hp, 12V, 1200 Rpm | (N992)

Art. No.: ob_obn992-c81

Key Features:

Material: Bronze housing, stainless steel shaft
Port Size: 3/8" NPT
Seal Type: Buna (NBR) lip seal (standard); FKM, PTFE, and mechanical seals optional
Motor: 1/4 HP, 12V DC, 1200 RPM
Max Pressure: 150 PSI (lubricants), 100 PSI (non-lubricants)
Max Speed: 1750 RPM
Temperature Range: 32°F to 140°F (standard); consult factory for extended range
Bearings: Carbon graphite, self-lubricating
Mounting: Close-coupled to DC motor
Suction Lift: Up to 20 feet
Drive Options: Direct motor coupling

Lead times temporarily extended to 32 weeks.

$2,345.37

Prices for items exclude shipping costs and taxes. Depending on your delivery address, taxes may vary at checkout.

Request a Quote

The OBN992-C81 is a bronze close-coupled rotary gear pump with an integrated 1/4 HP, 12V DC motor operating at 1200 RPM. Designed for compact and efficient fluid transfer, this positive displacement pump delivers consistent flow and pressure with excellent corrosion resistance.

Constructed with bronze housing, stainless steel shaft, and carbon graphite bearings, the OBN992-C81 ensures quiet operation and long service life. It is ideal for mobile and battery-powered systems requiring reliable performance in a compact footprint.

Recommended Applications:
Ideal for transferring oils, lubricants, and compatible chemicals in mobile, marine, and OEM systems requiring compact, corrosion-resistant, and pressure-stable performance. Not suitable for abrasive or solid-laden fluids.

Recommended Parts

Repair Kit, Buna with O-Ring | (OB10631)
